| Maximum working pressure | 1.6MPa |
| Minimum working pressure | 0.2MPa |
| Media | Liquid water |
| Media temperature | -5℃~200℃ |
| Operation | Pilot type |
| Voltage | AC:380V 220V 36V /50Hz DC:24V |
| Insulation grade | B class |
| The power supply range | -15%~+10% |
| Power | 26W |
| Response time | Open≤2 second/Close<3 second |
| Install way | The media flow direction should be consistent with the diraction indecated by the arrow.The coil should be positioned vertically upward.The woking medium should be clean and free olparticia impurities. |
